Dixon Round Bath Filler Mixer Tap

Product Overview

The Dixon Round Bath Filler Mixer Tap in Chrome is a sophisticated and practical addition to any contemporary bathroom. Combining a clean, minimalist aesthetic with reliable performance, this deck-mounted bath filler delivers precise water temperature and flow control, ensuring a consistently comfortable and luxurious bathing experience. The high-quality chrome finish provides a timeless, polished look that complements a wide range of bathroom styles, from classic to modern.

Key Features

• Sleek round design with a refined chrome finish
• Smooth single-lever operation for easy temperature and flow adjustment
• Hot and cold indicators for safe and intuitive use
• 3/4" ceramic cartridge for reliable, long-lasting performance
• Deck-mounted installation suitable for most standard baths
• Compatible with both low and high pressure water systems
• Suitable for use with combi boilers, gravity-fed, and pressurised systems

Technical Specification

• Product Type: Bath Filler Mixer Tap
• Finish: Chrome
• Cartridge: 3/4"
• Mounting: Deck Mounted
• Tap Holes Required: 2
• Inlet Connection Size: G3/4"
• Minimum Operating Pressure: 4.3 Bar
• Maximum Operating Pressure: 24.8 Bar
• Flow Rate at 0.5 Bar: 7.1 L/min
• Flow Rate at 1 Bar: 10.6 L/min
• Flow Rate at 3 Bar: 19.0 L/min
• Tap Base to Spout Height: 4.6 cm
• Spout Projection: 10.9 cm
• Hot & Cold Indicators: Yes
• Waste Included: No

UK Compliance & Standards

This bath filler mixer tap is designed and manufactured in accordance with current UK and European plumbing standards. It complies with the Water Supply (Water Fittings) Regulations 1999, making it suitable for use within UK domestic and commercial plumbing installations. We recommend that all installation work is carried out by a qualified and competent plumber in accordance with Building Regulations Part G and current Water Regulations guidance.

Installation Notes

The Dixon Round Bath Filler Mixer Tap requires a
